Specifications
| Measurement range | 2.54~100mm |
| Probe Frequency | 5MHz dual crystal probe. Custom automatic identification probe (defect and pit detection). |
| Probe style | Split probe |
| Probe diameter | Φ12.7mm |
| Probe line length | 4 foot cable |
| Display resolution | +/- 0.001 inches (0.01 mm) |
| unit system | Imperial and metric systems |
| Calibration method | 8 fixed and 1 programmable material speeds (in/µs): aluminum 2024-0.251; steel 4340-0.233; stainless steel 302-0.223; iron -0.232; cast iron -0.180; PVC-0.094; polystyrene -0.092; polyurethane -0.070; custom user |
| Measurement mode | Dual Element Probe Pulse Echo (PE): Off coating. Pulse Echo coating (PECT): On coating. Echo (EE): Through drawing. Single Element Probe Triple Echo (TCG): Through type. |
| Measurement speed | 0.0492 to 0.5510 inches/microsecond 1250 to 13995 meters/second |
| Storage Capacity | 5,000 readings, settings, and waveforms |
| Display | 1/2 " (12.7 mm) 4.5-bit LCD display. 3/8" (9.5 mm) 6 alpha LCD display. Both display backlit (on/off/automatic) |
| Interface | Bidirectional RS232 serial port with USB converter. Windows ® PC interface software |
| Environmental temperature | -20 ° to 140 ° F (-29 ° to 60 ℃) |
| Power Supply | Three 1.5V alkaline or 1.2V NiCad AA batteries |
| Host size | Length (9.0 inches/229 mm); Diameter (2.375 inches/60.33 mm) |
| Body material | High-strength clear plastic housing. Depth rating of 1000 feet (300 meters) |
| Weight | 1.5 lbs (0.680 kg) - with 3 AA batteries |
| memory | 32 trillion-bit non-volatile memory |
| programming | Storage Capacity is 1 file template. User specified size and Dimensions |
| Data Logging file format | Grid (alphanumeric); order (automatic identifier) |
| keyboard | Single button, magnetically coupled switch |
| Certificate type | Factory calibrated: traceable to national standards. IP68 rating. |
| pulse generator | Double square wave pulse generator |
| receiver | Dual Receiver Manual or AGC gain control with 110dB range (limited) |
| Timer | 25 MHz TCXO with single-shot 100 MHz 8-bit ultra-low power digitizer |
| Backlight off | Usually runs for 50 hours on alkaline batteries and 15 hours on nickel-cadmium batteries |
| Backlit | Usually 15 hours on alkaline batteries and 8 hours on Nicad |
| Automatic shutdown | After 5 minutes of inactivity |
| Pulse echo mode (PE) | (Pit and defect detection) Measurement range is 0.63 to 500mm |
| Pulse echo coating mode (PECT) | (Material, coating, pit and defect detection): Material: 0.63 to 500 mm. coating: 0.01 to 2.54 mm |
| Echo Mode (EE) | Via coatings and coatings) in sizes from 2.54 to 102 mm. The range will vary depending on the coating +/- |
| Triple Echo Mode (TCG) | Dimensions in steel by paints and coatings are 1 to 150 mm. Range will vary depending on Coating thickness, material type and probe |
Packing list
Host X1, PT-074-2906 underwater probe, coupling agent X1, No. 5 battery X2, factory certificate x1, Chinese and English instructions x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
