Specifications
| Conductivity range | 0uS/cm~200.0mS/cm |
| EC resolution | 1uS/cm |
| Measurement Accuracy of conductivity | 0.5% FS |
| Salinity range | 0.0~70.0ppt |
| Salinity resolution | 0.1ppt |
| Measurement Accuracy of salinity | 0.1ppt |
| Measurement range | -10.0~120.0℃ |
| Temperature Resolution | 0.1℃ |
| Measurement Accuracy | ±0.3℃ |
| Electrode type | K = 0.475 four-wire (ring) electrode |
| current output | A set of 4~ 20mA reversible, isolated current outputs |
| Insulation Voltage/maximum load | 500VDC/550Ω |
| Relay Control Output/Maximum Load | Two sets of ON/OFF control in the system/2.5A/230VAC |
| protective measures | 4-Digit password protection |
| Power Supply | 110或230VAC,50/60Hz |
| opening size | 92*92mm |
| Dimensions | 96*96*148mm |
| Shop Accessories | Conductivity electrode, sheath, sealing box |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/2961/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
