Specifications
| Measuring method | Platinum plate method |
| Operation mode | Automatic lifting, automatic measurement |
| Measurement range of surface tension | 0~400mN/m |
| clear range | 0~400 mN/m |
| Resolution | 0.01mN/m |
| Precision | ≤ +/- 0.04 mN/m (25 ℃ +/- 2 ℃, test secondary distillation water) |
| Repeatability | ≤±0.04mN/m |
| Data Display | When the platinum plate is tested, the displayed value is the surface tension value |
| Display mode | STN wide Viewing Angle backlight LCD display |
| Measurement time | 3-5 seconds for measurement of low viscosity sample fluids in automatic operation mode |
| Temperature range | RT or 0~100 ℃ (Glass clip cup and external Thermostatic bath are required) |
| Interface | RS232C |
| Power | AC220V, 50/60HZ |
| Control mode | Numerical control keys |
| Optional | Increase platinum ring method |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29628/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
