Specifications
| Measured value | 750N / 77Kgf / 120lbf |
| resolution | 0.5N / 0.05Kgf / 0.1lbf |
| Indication relative error | ±5% |
| Belt requirements under test | Width: ≤ 50mm; Thickness: ≤ 10mm |
| Force unit | N、Kgf、lbf |
| Power Supply | Lithium battery: 3.7V/1000mAh |
| Charger | AC input: 220V/50HZ, DC output: 5V/1A |
| Operating temperature | 0℃-40℃ |
| Storage temperature | -20℃-70℃ |
| Relative Humidity | 15%-80% |
| Operating Environment | No vibration and corrosion medium around |
| Host size | 208*70*41mm |
| Net Weight | Approx. 600g |
| Sensors size | 60*76*78mm |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29629/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
