Specifications
| Measured value | 300N |
| Load Graduation | 0.05N |
| Displacement scale stroke | 100mm |
| platen diameter | Ф78.5mm |
| Measurable maximum free length of spring | 100mm |
| effective travel | ≤125mm |
| Maximum pressure space | ≤245mm |
| Maximum space for pulling | 155mm |
| Dimension | 300*225*610mm |
| Net Weight | 18kg |
| Precision | ±0.5% |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29630/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
