Specifications
| Meet the standard | IEC651.2，ANSI1.4.2 |
| Measurement parameter | LP-ordinary sound level measurement, Leq-equivalent sound level measurement, Lmax-maximum sound level measurement, LN-statistical sound level measurement |
| Lp-Normal Sound Level Measurement range | A Weighting: 30~130dB; C Weighting: 35~ 130dB; Linear: 40~130dB |
| Leq - Equivalent Sound Level | 30~130dB (time can be selected from 10 seconds, 1 minute, 5 minutes, 10 minutes, 15 minutes, 30 minutes, 1 hour, 8 hours, 24 hours) |
| LN-Statistical Sound Level Measurement range | 0~100% |
| resolution | 0.1dB |
| Precision | 1dB |
| Frequency Weighting | “A”/“C”/“F”（Flat） |
| time Weighted | Fast/slow |
| microphone | 12.5Mm condenser microphone |
| Memory function | 30 groups |
| Built-in calibrated signal | 94dB |
| Frequency range | 20~12,500Hz |
| Alarm value setting | 30~130dB |
| Alarm output | LED optional relay touchpoint |
| Power supply Voltage indication | Low Voltage indication |
| Power supply Voltage | 4 AA batteries |
| External power socket | 6V, DC, 100mA |
| Dimension | 171*72*34mm |
| Weight | 140G (without battery) |
