Specifications
| Display | digital display |
| Measuring range | 3~200000mPa·s |
| Rotor Specifications | 18 #, 25 #, 31 #, 34 #(optional ULR0 rotor) |
| Rotor speed | 0.3/0.6/1.5/3/6/10/12/15/20/25/30/40/50/60/70/80/90/100 A total of 18 kinds |
| Reproducibility | ±1%F.S |
| Measurement Accuracy | ±2% |
| Capacity | 7~11ml |
| Data Interface | There are two RS232 interfaces, which can connect printers and computers |
| Dimensions | 300*300*450mm |
| Operating language | Chinese |
| Temperature probe interface | Standard |
| Measuringflask depth | About 70mm |
| Measuringflask outer diameter | 28mm |
| ULR (No. 0 rotor) range | 1~1000mPa·s |
| No. 18 rotor range | 3~10000mPa·s |
| No. 25 rotor range | 4.8~ 1.6 million mPa·s |
| No. 31 rotor range | 30~100,000 mPa·s |
| No. 34 rotor range | 600,000~200,000 mPa·s |
| ULR (No. 0 rotor) sample Volume | 21ml |
| No. 18 rotor sample Volume | 7ml |
| No. 25 rotor sample Volume | 9ml |
| No. 31 rotor sample Volume | 10.5ml |
| No. 34 rotor sample Volume | 11ml |
Packing list
Viscometer host * 1, lifting column * 1, base * 1, 18 #, 25 #, 31 #, 34 #rotor * 1 each, connecting frame * 1, sample cylinder * 1, operation manual * 1, power adapter * 1, certificate/warranty card * 1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29658/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
