Specifications
| Display | Backlit LCD, digital display |
| Measuring range | 5~2000000mPa·s |
| Rotor Specifications | 21 #, 27 #, 28 #, 29 #(0 #optional) |
| Rotor speed | 0.5/1/2/2.5/4/5/10/15/20/25/30/40/50/60/70/80/90/100rpm |
| Reproducibility | ±1%F.S |
| Measurement Accuracy | ±2% |
| Capacity | 7.8~11.5ml |
| Data Interface | There are two RS232 interfaces, which can connect printers and computers |
| Dimensions | 300*300*450mm |
| Operating language | Chinese |
| Temperature probe interface | Standard |
| No. 0 rotor (optional) range | 6.4~1K；K=1000 |
| No. 21 rotor range | 50-100K；K=1000 |
| No. 27 rotor range | 250-500K；K=1000 |
| No. 28 rotor range | 500-1M；M = 1000000 |
| No. 29 rotor range | 1K-2M万；M = 1000000 |
| ULR (No. 0 rotor) sample Volume | 21ml |
| No. 21 rotor sample Volume | 7.8ml |
| No. 27 rotor sample Volume | 11.3ml |
| No. 28 rotor sample Volume | 12.6ml |
| No. 29 rotor sample Volume | 11.5ml |
Packing list
Viscometer host * 1, lifting column * 1, base * 1, 21 #, 27 #, 28 #, 29 #rotor * 1 each, connecting frame * 1, sample cylinder * 1, operation manual * 1, power adapter * 1, certificate/warranty card * 1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29659/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
