Specifications
| Weighing range | 410g |
| readability Accuracy | 0.1mg |
| Calibrating function | Automatic internal calibration |
| Minimum weighing value | 0.4mg |
| linearity error | ±0.0005mg |
| Repeatability Error | 0.1Mg if Weight ≤ 220g; 0.1m from 220g to 310g; 0.35mg from 310g-610g |
| Settling time | ≤4s |
| Range drift | (+10~+30℃）：±2ppm/℃ |
| Pan size | F80mm |
| Power | 110 ~ 230 VAC 50 / 60Hz subsist24V / 500mA / 13VA |
| Instrument net Weight | 5.8kg |
| Dimensions | 345*215*345mm |
| display | LCD backlit liquid crystal display with adjustable contrast |
| Gross Weight | 8.25kg |
| Operating Temperature | 5-25℃ |
| Options | RS232C & RS486、Printer |
| Wind Shield size | 162*171*225mm |
| External electronic box size | 175×105×50mm |
| External electronic box Weight | 500 g |
Packing list
After-sales instructions
Warranty days: 365 days
For non-artificially caused product quality problems, the manufacturer provides 1-year free warranty service, except for accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29665/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
