Specifications
| PH range | -2.00~16.00pH |
| PH Measurement Accuracy | ±0.01pH |
| Resolution | 0.01pH |
| Measurement range | -10.0~120.0℃ |
| Impedance | >10^13Ω |
| Power Supply | 12 ~ 36 V DC |
| Weight | 600grams |
| Measurement range mV | -1000~1000mV |
| mV resolution | 1mV |
| Measurement Accuracy of mV | ±1mv |
| Measurement range | 10.0~120.0℃ |
| Temperature Resolution | 0.1℃ |
| Measurement Accuracy | ± 0.3 ℃ |
| pH buffer recognition | US (4.01, 7.00, 10.01) or NIST (4.00, 6.86, 9.18) users can choose |
| pH electrode zero correction range | ± 90 mV |
| pH electrode slope (slope) identification | ±30% |
| input selection | Users can choose between pH and ORP. |
| Current output range | 4 - 20 mA (insulation), programmable design |
| Environmental temperature | 0~50℃ |
| Shell material | Case IP 65, 1/4 DIN case, depth 148 mm |
| Temperature compensation method | Automatic or manual operation |
Packing list
Host X1, IP-600-9TH (5 meters) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
