Specifications
| PH range | -2.00~16.00pH |
| PH Measurement Accuracy | ±0.01pH |
| Resolution | 0.01pH |
| Impedance | ＞10^12Ω |
| Power Supply | 230VAC,50/60Hz |
| Dimensions | 96*96*148mm |
| Weight | 960g |
| pH Buffer Identification Solution | Users can choose from any of 4.01, 7.00, 10.01 or 4.00, 6.86, 9.18 |
| pH electrode zero/slope compensation | ±100mV/±30% |
| Measurement range mV | -2500~2500mV |
| Measurement range mV | -6499~6499mV |
| mV resolution | 1mV |
| Measurement Accuracy of mV | 0.1%F.S |
| Measurement range | -10.0~120.0℃ |
| Temperature Resolution | 0.1℃ |
| Temperature sensor | Thermistor, 10K/25 ℃ |
| Current output range | 4~ 20mA reversible, isolated current output |
| Insulation Voltage/maximum load | 500VDC/500Ω |
| Control mode | In-system ON/OFF control |
| Maximum load | 2.5A/230VAC |
| key | All have sound feedback effects |
| Various protection measures | 4-Digit password protection |
| opening size | 92*92mm |
| Protection level | IP65 |
| Shop Accessories | pH electrode, oxidation electrode, sheath, sealing box |
| Measurement Accuracy | ±0.3℃ |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year warranty for the instrument and 1 month for consumables such as electrodes (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/2971/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
