Specifications
| PH range | 0~14.0pH |
| PH Measurement Accuracy | ±0.1PH |
| Resolution | 0.1pH |
| Impedance | Greater than 10 ^ 12 ohms |
| Power Supply | 115/230 VAC ±15%,50/60 Hz |
| Dimensions | 96*48*172mm |
| Weight | 0.69 kg |
| Measurement range mV | -1990~1990mV |
| mV resolution | 10mV |
| Measurement Accuracy of mV | ±0.1% ±1 digit |
| Measurement range | 0~100℃ |
| Temperature Resolution | 1℃ |
| Measurement Accuracy | 1 ±1 digit |
| Recorder, output (ph) | 1400 mV |
| Recorder, output (mV) | -1990 ~ 1990 mV |
| Recorder, output (temperature) | 1000 mV |
| Two-point on/off control | pH or ORP (user selectable) |
| Idle zone (dead band, no sensing zone) | +/- 0.1 pH (per set point) |
| Relay, output | 8a at 115 VAC,4a at 230 VAC |
| read display | 0.5 "active, red LED display |
Packing list
Host X1, with IP-600-10 (20 meters) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year warranty for the instrument and 1 month for consumables such as electrodes (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/2974/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
