Specifications
| Weighing range | 20kg |
| readability Accuracy | 0.1g |
| Operating conditions temperature | 5℃-35℃ |
| Repeatability Error | ±3d |
| linearity error | ±3d |
| Settling time | ≤ 4s |
| Sensitivity drift | ±3d |
| tetragonal error | ±3d |
| Weighing mode | g, oz, ct... |
| Pan size | 305*230mm |
| Dimensions | 395*118*320mm |
| Packaging Dimensions | 415×165×430mm |
| display | 7 inch high definition display |
| Data Interface | RS232 / RJ45 / USB... |
| input and output | Data output excel, parameter import (USB) |
| Internal calibrated | Fully automatic time trigger calibrated (optional) |
| Test function | Counting, Checking, Percentage, Density Density |
| Function extension | Internal calibrated/under hanging weighing/external display... |
| Weighing Unit | Input: 220V 50HZ/110V 60HZ；Output:12V |
| Mechanical part | Input: 220V 50HZ/110V 60HZ；Output:12V |
| Battery | 6V/4Ah |
Packing list
After-sales instructions
Warranty days: 365 days
For non-artificially caused product quality problems, the manufacturer provides 1-year free warranty service, except for accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29742/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
