Specifications
| Measurement range | 0.5-400.0mm |
| Probe Frequency | 5MHz |
| Probe diameter | Φ10mm |
| Probe contact temperature | -10~300℃ |
| Lower limit of pipe measurement | Φ20*3mm |
| measurement error | ±(0.5%H+0.04)mm |
| Display resolution | 0.01Mm optional |
| unit system | Metric/Imperial |
| Calibration method | Zero point calibrated, two point calibrated |
| Storage Capacity | Can store 20 groups (up to 100 Measured values per group), view and delete |
| Speed of sound | 1000~9999m/s |
| Display | 128 × 64LCD display, high luminance EL backlight |
| Interface | RS232 interface for exporting data |
| Power Supply | 2 AA type alkaline batteries 1.5V |
| Operating Time | Up to 250 hours of continuous operation (without backlight) |
| Host size | 150×74×32mm |
| Weight | 238g |
| minimum thickness value capture capability | Capable of capturing minimum thickness values |
| Measurement speed | 4 times/second for single point measurement, 20 times/second for scanning mode |
| Calibrating block | 4.0Mm (steel) |
| Probe Specifications | φ 6 mm (optional), φ 10 mm (optional), φ 12 mm (optional) |
| Optional probe | 2MHz, 7MHz, 5MHz (high temperature), 5MHz (standard) |
Packing list
Host x1, 5MHz high temperature probe X1, high temperature coupler X1, 4.0 mm steel calibrated block X1, battery (non-aviation) X2
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29792/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
