Specifications
| Scanning range | 0~9999mm |
| Speed of sound | 1000~15000m/s |
| number of storage channels | 500 |
| Number of stored waveforms | 5000 |
| video recording | 5min×10 |
| Gain Range | 0dB~100dB |
| display delay | -15μs~+3400μs |
| Probe zero | 0μs~1000μs |
| Frequency range | 0.2~15MHz |
| impedance matching | 50/75/150/500Ω |
| electrical noise level | ≤10% |
| Frequency of sexual repeability | Automatic low, automatic medium, automatic high, 5~ 1000Hz |
| Sensitivity margin | ≥ 62dB |
| Dynamic range | ≥ 40dB |
| Horizontal Linearity | ≤ 0.1% |
| Vertical Linearity | ≤ 3% |
| Far field resolution | ≥ 32dB |
| pulse intensity | fixed |
| pulse width | 50~1000ns |
| Storage Capacity | 1GB |
| Environmental temperature | -10~50℃ |
| Operating Time | ≥20H |
| Operating language | Simplified Chinese/English |
| Communication interface | High-speed USB interface |
| size | 263*170*61mm |
| Power Supply | Direct current (DC) 9V; lithium battery works continuously for more than 6 to 8 hours |
| Power Supply | 220V,50Hz,8.4V |
| Machine Weight | About 1.3Kg (including battery) |
Packing list
Host X1, lithium battery X1, power adapter X1, AC power cable X1, probe cable X2, straight probe X1, oblique probe X1, USB cable X1, U disk X1, host belt X1, instrument suitcase X1, operation manual X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29794/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
