Specifications
| Measurement range | 30.6~102.6HS、170~960HLD、19~651HB、13.5~101.7HRB、17.9~69.5HRC、59.1~88HRA、80~1042HV |
| Measurement direction | 360 ° (vertical down, diagonal down, horizontal, diagonal up, vertical up) |
| Measurement material | Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, ductile cast iron, cast aluminum alloy, copper zinc alloy (brass), copper tin alloy (bronze), pure copper, wrought copper |
| Error of indication | ±6HLD |
| Indication Repeatability | ±6HLD |
| Hardness system | HL/HB/HRC/HRA/HV/HS |
| Upper and lower limit setting range | 170~960HLD |
| Display | Highlight OLED128x64 dot matrix display |
| Indication calibrated | Adjustment with indication software |
| Data storage | Maximum 600 Groups (Impact 32~ 1) |
| Communication interface | RS232 |
| Working time | About 100 hours |
| working language | Chinese |
| Dimensions | 132 * 82 * 33Mm (host) |
| Weight | 0.6KG (host) |
Packing list
Host X1, D-type Impact device X1, D-type Richter Hardness block X1, nylon brush AX1, small support ring X1, operation manual X1, instrument case X1, battery X2
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29799/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
