Specifications
| Force range | 20~3000N |
| Force resolution | 1N |
| Plate size | 300*300mm |
| Working Travel | 5~300mm |
| Plate parallelism | ≤1mm |
| Pressurization speed | 12.5 +/- 12.5mm/min 1~ 99mm/min Any setting |
| return speed | 5~120mm/min |
| monitor | 240 × 128 dot matrix liquid crystal display |
| printout | Thermal Microprinter |
| Communication interface | Standard RS232 interface (optional) |
| meet the standard | GB/T2679.8-1995 GB/T4857.4 GB/T4857.3, GB/T0032-2006 |
| Environmental conditions | Temperature 10~30 ℃, Relative Humidity < 85% |
| Dimensions | 550*415*790mm |
| Weight | Approx. 70kg |
Packing list
whole machine X1, power cord X1, printing paper X1, manual X1, certificate X1, packing list X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29847/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
