Specifications
| Force range | 10~500N |
| Force resolution | 0.1N |
| Indication variability | ≤1% |
| Specimen holder free spacing | 0.7±0.05mm |
| Pressurization speed | 3±1mm/min |
| Sample holding surface size | 30mm × 15mm |
| Data storage quantity | Can store 5000 batches of data (shutdown without loss); 20 test data vertically and horizontally under each batch |
| monitor | 7 inch, 800 * 480 pixel color resistive touch screen |
| Communication interface | USB 2.0 or RS232 optional |
| printout | Thermal printer |
| Power supply Voltage | AC 100-240V 50/60Hz 50W reliable grounding |
| Operating Environment | 20℃±10℃ |
| gas source | Above 0.4Mpa |
| Dimensions | 455*425*280mm |
| Weight | 37Kg |
| Error of indication | ±1% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29849/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
