Specifications
| Weighing range | 510g |
| Readability | 0.1mg |
| Repeatability Error | 0.2mg |
| Linearity | 0.3mg |
| Stabilization time | 4s |
| Measurement unit | G, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl. H, tl. S, tl. T, custom unit |
| Minimum Weight | 400mg |
| Operating temperature | 10~30℃ |
| Power supply Voltage | 24VDC, 50/60Hz, 500mA adapter |
| Adjustment | Auto Internal Cal |
| monitor | 15Mm high digital graphic display |
| Wind Shield | Yes. |
| Wind Shield size | 192*195*230mm |
| Shell material | ABS plastic shell |
| Pan Size | Φ80mm |
| Overall size | 224×374×338mm |
| Net Weight | 7kg |
| function mode | Weighing, Part Counting, Percent Weighing, Inspection Weighing, Animal/Dynamic Weighing, Density Weighing, Formulation Function, Display Lock |
| Interface | RS-232 |
Packing list
machine X1, certificate of conformity X1, manual X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29918/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
