Specifications
| Frequency range | 0.1~26.5MHz |
| Speed of sound | 200~19999m/s |
| Scanning range | 0~10000mm |
| Dynamic range | ≥36dB |
| Vertical Linearity | ≤2.5% |
| Horizontal Linearity | ≤0.1% |
| resolution | >40dB(5P14) |
| Sensitivity margin | 62dB (depth 200mm-2 flat bottom hole) |
| digital suppression | (0~80) %, does not affect linearity and gain |
| electrical noise level | ≤10% |
| Flaw detection channel | 100 sets of flaw detection working channels |
| probe interface | LEMO 00 interface, dual crystal probe |
| Probe type | Straight probe, oblique probe, dual crystal probe, penetration probe |
| gate | Inlet gate, loss gate; single gate reading, double gate reading |
| Alarm function | Beep alarm, LED light alarm |
| Power Supply | Direct current (DC); lithium battery works continuously for more than 10 hours |
| Dimension | 263*170*61mm |
| Environmental temperature | (-10~50)℃ |
| Relative Humidity | (10~98)%RH |
| Detection method | Positive half-wave, negative half-wave, full-wave, RF detection |
| Gate reading | Single and double gate readings are optional; peak readings in the gate |
| Storage Capacity | It can store 50,000 flaw detection echo signals and parameters |
| real time clock | Tracking record of real-time flaw detection date and time, and record storage |
| Communication interface | USB2.0 high-speed communication transmission interface |
Packing list
Host x1, porcelain bottle special probe x20, power adapter x1, lithium battery pack x1, BBD series cable x1, product Encasement box x1, instruction manual x1, certificate of conformity + packing card + warranty card x1, PC special porcelain bottle insulator flaw detection communication software x1, factory inspection report x1
After-sales instructions
Warranty days: 365 days
