Specifications
| Brinell scale | HBW2.5/62.5、HBW2.5/187.5、HBW5/125、HBW5/750、HBW10/100、HBW10/1500、HBW10/3000、HBW10/250、HBW10/500、HBW10/1000 |
| test force | 62.5kgf(612.9N);100kgf(980.7N);125kgf(1226N);187.5kgf(1839N);250kgf(2452N);500kgf(4903N);750kgf(7355N);1000kgf(8907N);1500kgf(14710N);3000kgf(29420N) |
| Maximum height of specimen | 220mm |
| Measurement unit | 0.005mm |
| Load time | 0~60s |
| Hardness testing range | 8~650HBW |
| Microscope magnification | 20X |
| Execution standards | GB/T231.2，JJG150 |
| Indenter - Outer Wall Distance | 135mm |
| Hardness reading | look-up table |
| Power | AC220+5%,50~60Hz |
| Dimensions | 520*210*745mm |
| Host Weight | About 90kg |
Packing list
Measurement Microscope x1, Standard Hardness Block x3, Power Cord x1, Fuse x2, Diameter 2.5/5/10mm Carbide Ball Head x1, Large/Medium/V Type Test Bench x1, Product Certificate x1, Product Instruction Manual x1, Brinell Comparison Table x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29993/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
