Specifications
| Machine Weight | 36kg |
| Dimensions | 433*228*523mm |
| Power | AC220V/50~60Hz |
| Display | LCD display |
| The maximum distance from the center of the indenter to the machine wall | 98mm |
| Test force holding time | 0-60s |
| Maximum height of applicable material | 100mm |
| Measurement unit | 0.0625mm |
| Microscope magnification | 400X (during testing) X100 (during observation) |
| Loading method | manual |
| Indenter and objective lens conversion method | manual |
| Hardness symbol | HV1、HV5、HV10、HV20、HV30、HV50 |
| Measurement range | 1HV~2967HV |
| test force | 10/25/50/100/200/300/500/1000gf |
Packing list
Microscopic Vickers indenter x1, weight x6, weight rod x1, cross test bench x1, screw batch x2, 10 * scale microscope eyepiece x1, power cord x1, 10 × objective x1, 40 × objective x1, level x1, mirror hole x1, flat clip test bench x1, horizontal adjustment screw x4, spare fuse x2, microscopic Vickers Hardness block x2 (HV0.2 medium block/HV1 high block)
After-sales instructions
Warranty days: 365 days
