Specifications
| Frequency range | 0.2~15MHz |
| Speed of sound | 1000~15000m/s |
| Scanning range | 0~9999mm |
| Storage Capacity | 500 sets of flaw detection parameter channels; can store 1000 flaw detection echo signals and parameters |
| real time clock | Tracking record of real-time flaw detection date and time, and record storage |
| Communication interface | USB2.0 high-speed communication transmission interface |
| Battery module | High-Capacity lithium battery module, online charging and offline charging two charging methods, convenient for flaw detection personnel to use |
| Dynamic range | ≥40dB |
| Vertical Linearity | ≤3% |
| Horizontal Linearity | ≤0.1% |
| Far field resolution | >32dB |
| digital suppression | (0~80) %, does not affect linearity and gain |
| electrical noise level | ≤10% |
| Flaw detection channel | 500 sets of flaw detection working channels |
| probe interface | Q9-Q9 |
| Probe type | Straight probe, oblique probe, dual crystal probe, penetration probe |
| gate | Inlet gate, loss gate; single gate reading, double gate reading |
| Alarm function | Beep alarm, LED light alarm |
| Power Supply | Direct current (DC) 9V; lithium battery works continuously for more than 6 to 8 hours |
| Dimension | 263*170*61mm |
| Environmental temperature | (-10~50)℃ |
| Relative Humidity | (20~95)%RH |
Packing list
whole machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
