Specifications
| Measurement range | 1.0Mm~ 230.0mm (steel) |
| Probe Frequency | 5MHz |
| Probe diameter | 8mm |
| Lower limit of pipe measurement | Φ20*3mm |
| measurement error | +/- 0.04mm (< 10mm )；( +/- 0.5% H + 0.01mm) (> 10mm); H is the actual thickness of the measured object |
| Display resolution | 0.01mm |
| unit system | Metric or imperial (optional) |
| Calibration method | Zero point calibrated, two point calibrated |
| Measurement mode | There are two Operating Modes of thickness measurement: single-point thickness measurement and scanning thickness measurement |
| Storage Capacity | 2000 thickness measurements can be stored |
| Speed of sound | 1000~9999m/s |
| Display | High contrast ratio segment LCD display, high luminance EL backlight |
| Operating language | Chinese |
| Power Supply | 2 AA size alkaline batteries (No. 5) |
| Operating Time | More than 160 hours (without backlight) |
| Host size | 170×80×38mm |
| Measurement speed | 4 times/sec for single point measurement, 10 times/sec for scanning mode |
Packing list
host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30002/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
