Specifications
| eyepiece | Big Vision WF10X |
| Total Magnification | 7X~63X |
| eyepiece interface | Φ30mm |
| eyepiece field of view | Φ22mm |
| Eyepiece parfocal distance | 10mm |
| trinocular observation head | Hinged binocular, the observation angle is 45 degrees, the pupil distance is 48~ 75mm, and the left and right eyepieces have visibility adjustment, and the adjustment range is -5~ + 5. |
| working distance | 110mm |
| Transmissive Illumination Light source | 3W LED/30W halogen (optional), adjustable luminance |
| Reflection Lighting source | 3W LED/30W halogen (optional), adjustable luminance |
| Light source of epifluorescence illumination | 3W × 2LED blue/green (standard)/purple/ultraviolet (optional) |
| Host Power | Input: Adaptable AC Voltage 85V~ 265V 50/60Hz, output 12V |
| Excitation Color Filter Set - Ultraviolet (UV) | Excitation wavelength: 360nm~ 370nm; Emission plate wavelength: 425nm |
| Excitation filter group - purple (V) | Excitation wavelength: 390nm~ 400nm; Emission wavelength: 455nm |
| Excitation filter set - blue light (B) | Excitation wavelength: 460nm~ 470nm; Emission plate wavelength: 515nm |
| Excitation Filter Set - Green (G) | Excitation wavelength: 520nm~ 530nm; Emission plate wavelength: 590nm |
Packing list
Instrument host x1, objective lens: 0.7-6 continuous zoom objective x1, eyepiece: 10X/22x2, observation head: trinocular x1, power cord x1, dust cover x1, installation instructions x1, fluorescent module B/Gx1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30015/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
