Specifications
| Measurement structure | D/8, including specular reflection (SCI) |
| Measurement index | Light spectrum reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, color difference (delta E * ab, delta E * cmc, delta E * 94, delta E * 00), whiteness, yellowness, Blackness, colour fastness, discoloration fastness, Tint, color density CMYK, isochromatic index Milm, Munsell, hiding power, force (dyestuff strength, tinting strength) |
| Lighting source | LED (Full Band Balanced LED Light source) |
| Measurement caliber | Φ8mm |
| wavelength interval | 10nm |
| Wavelength range | 400~700nm |
| Stability measurement | Delta E ≤ 0.1 (every 5s measurement whiteboard 30 times) |
| Measurement time | 1s |
| Interface | USB, Bluetooth |
| Measurement light source | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84 |
| Viewing Angle | CIE 2°/10° |
| Display | IPS full color screen (135 * 240, 1.14inch) |
| Battery life | 4.2V/760mAh, a single full charge can be continuously measured 10,000 times |
| Operating language | Simplified Chinese, English |
| Calibrate | Automatic calibration |
| Software support | Andriod,IOS,Windows |
| Weight | Approx. 90g |
| Volume | Diameter: 31mm, Height: 102mm |
Packing list
Host X1, Data Cable X1, Manual X1, Warranty Card X1, Certificate X1, Encasement Box X1
After-sales instructions
Warranty days: 365 days
1. The manufacturer of this product promises to provide free warranty during the warranty period
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30055/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
