Specifications
| Flow Rate | Class I ultrapure water ≥ 2L/min |
| Produced water quality | tertiary water |
| Ultrapure water quality | Level I |
| Inlet source | tap water |
| Operating Environment | Temperature 5~ 40 ℃, avoid direct sunlight |
| Power | 220V/50HZ, Power: 150W |
| Host size | 470x280x520mm |
| Application standard | ISO3696:1987, GB/T6682-2008, CLSI, ASTM D1193-06, Standard specifications for Reagent Grade Water, EP, USP, Purified Water Standard of Chinese Pharmacopoeia |
| RO Flow Rate | 240L/day |
| Inlet source | TDS: < 200ppm; pH: 6.5-8; Free Chlorine: < 1ppm; Pressure MIN Minimum: 0.2MPa; Pressure MAX Maximum: 0.5MPa; Temperature: 5-35 ℃ |
| Water production index - pure water | Conductivity: < 10μs/cm@25 ℃ meets the Chinese laboratory water standard GB/T6682-2008 Class III water standard |
| Water production index - ultrapure water | Electrical resistivity: 18.25MΩ .cm@25 ℃; particles (> 0.2μm): < 1/ml; microorganisms < 1/ml; TOC < 10ppb |
| Pure water quality | Level 3 water standard |
Packing list
PP Fiber Filter x1, Activated Carbon Filter x1, Booster Pump x1, RO Membrane Module x1, Pure Water Tank x1, Conveyor Pump x1, UV oxidation sterilization device x1, Purification Column x1, Water Quality Resistance meter x1, Control system x1,
After-sales instructions
Warranty days: 365 days
