Specifications
| Capacity selection | 20KG |
| Measurement Accuracy | ±1% |
| force resolution | 1/200000 |
| Test speed range | 0~300mm/min |
| effective travel | 600mm |
| Test space | 120mm |
| Force unit | kgf、gf、N、kN、lbf |
| stress unit | MPa、kPa、kgf/cm2、lbf/in2 |
| shutdown mode | Upper and lower limit safety setting, specimen breakpoint sensing |
| result output | micro printer |
| Power system | speed regulating motor |
| optional configuration | Tension clamp (conventional) |
| Machine Weight | About 40kg |
| Power | 1PH、AC220V、50/60Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30709/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
