Specifications
| Measuring range | 15~10000mN.m |
| Accuracy | Below 50mN ± 0.6mN, remaining ± 1% |
| resolution | 0.1mN |
| Indication of variability | ≤1% |
| bending length | 50mm、25mm、20mm、15mm、10mm、5mm(±0.1mm) |
| Bending angle | 7.5°±0.3、15°±0.3 |
| Test speed | 200°±20°/min |
| printout | Modular integrated thermal printer |
| Display | 5.7In LCD display with Linear dispersion diagram |
| printout | Modular integrated thermal printer |
| Operating Environment | Temperature (20 ± 10) ℃, humidity < 85% |
| Dimensions | 340*330*340mm |
| Weight | About 28kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30743/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
