Specifications
| Temperature range | -40~RT℃ |
| Temperature Fluctuation | ±0.3±K |
| Temperature display | LED |
| Temperature display Accuracy | 0.1℃ |
| Temperature Control mode | Smart PID |
| Temperature sensor | Pt100 |
| Cooling Capacity (20 ℃) | 800W |
| Pump type | Pressure/suction pump |
| Maximum pump pressure | 0.3bar |
| Maximum suction of pump | 0.2bar |
| Flow rate of pump | 22L/min |
| Pump connection interface | ID=8mm |
| Tank Volume | 6L |
| Dimensions | 220*420*495mm |
| Instrument fixing method | desktop |
| Allow continuous operation | 100% |
| Environmental temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
| Power supply Voltage | 220V 50Hz |
Packing list
After-sales instructions
Warranty days: 365 days
