Specifications
| Temperature range | -30~RT℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature display | LED |
| Temperature display Accuracy | 0.1℃ |
| Temperature Control mode | Smart PID |
| Temperature sensor | Pt100 |
| Cooling Capacity (20 ℃) | 2400W |
| Maximum pump pressure | 1.0bar |
| Flow rate of pump | 22L/min |
| Pump connection interface | RC1/2mm (4-point inner tooth) interface, which can be matched with various specifications of pipelines |
| Tank Volume | 17L |
| Dimensions | 400*550*670mm |
| Instrument fixing method | floor type |
| Allow continuous operation | 100% |
| Environmental temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30750/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
