Specifications
| Temperature range | 5~35℃ |
| Temperature Fluctuation | ±0.1℃ |
| Temperature display | liquid crystal |
| Temperature display Accuracy | 0.1℃ |
| Temperature Control mode | PID |
| Temperature sensor | Pt100 |
| Cooling Capacity (25 ℃) | 1200W |
| Maximum pump pressure | 4.0L/Min |
| Flow rate of pump | 2-20L/min |
| Pump connection interface | RC1/2 (4-point inner teeth) interface, which can be matched with various specifications of pipelines |
| Tank Volume | 13.0L |
| Dimensions | 400*550*670mm |
| Instrument fixing method | floor type |
| Allow continuous operation | 100% |
| Environmental temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
| Rated power | 750W |
| Power supply Voltage | 200~230VAC/50Hz |
| Maximum pump pressure | 3.5bar |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30755/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
