Specifications
| Temperature range | 5~35℃ |
| Temperature display | liquid crystal display |
| Temperature Fluctuation | ±1.0℃ |
| cooling Capacity | 35000W |
| Flow rate of pump | 120L/min |
| Tank Volume | 200L |
| Dimensions | 775*1650*1800mm |
| Interface size | 4-Point inner teeth, can be matched with joints and pipes of different specifications |
| Instrument fixing method | floor type |
| Allow continuous operation | 100% |
| Environmental temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
| Power supply Voltage | 200~230VAC/50Hz |
| Temperature display Accuracy | 0.1℃ |
| Maximum pump pressure | 3.4bar |
| Temperature display Accuracy | 0.1℃ |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30783/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
