Specifications
| Temperature range | -20~150℃ |
| Tank Volume | 20L |
| Pump flow | 22L/min |
| Temperature fluctuation | ±0.05~0.1℃ |
| Temperature display | LED |
| temperature resolution | 0.1℃ |
| Temperature control method | Smart PID |
| Temperature transducer | Pt100 |
| Heating power | 2000W |
| Pump type | Pressure/Suction Pumps |
| Pump connection interface | M16x1 |
| Tank opening Dimensions | 295*297*150mm |
| Dimensions | 350*570*778mm |
| Instrument fixing method | Floor type |
| Allow continuous operation | 100% |
| Allowable environment temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
| Power | 200~230VAC/50Hz |
| Maximum pump pressure | 0.3bar |
| Maximum suction of pump | 0.2bar |
Packing list
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides free warranty services during the warranty period
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30818/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
