Specifications
| Measurement range | 0.65~500mm |
| Probe Frequency | 2~10MHz |
| Probe style | Split probe |
| Probe diameter | Φ8mm |
| Measurement error | H<10mm，±0.05mm；H≥10mm，±(±0.01+H/200) |
| Display resolution | 0.01Mm (measurement < 100mm); 0.1mm (measurement > 100mm) |
| unit system | mm |
| Calibration method | Speed of sound calibrated (reverse measurement Speed of sound) or single point calibrated |
| Measurement mode | Measurement mode and monitoring Measurement mode |
| Storage Capacity | 600 Measured values |
| Speed of sound | 1000~9990m/s |
| Display | LCD display with backlight |
| Operating language | Chinese |
| Application Software | none |
| Environmental temperature | -10~60℃ |
| Working Relative Humidity | <90%RH |
| Power Supply | 2 * 5 battery |
| Operating Time | 200h |
| Host size | 146*81*30mm |
| Weight | 300g |
| Application | Petroleum, chemical industry, metallurgy, shipbuilding, aviation, aerospace, etc |
| Data storage method | Manually stored measurements |
| shutdown mode | Standby for five minutes will automatically shut down |
| keyboard | 6-Key dustproof, oil-proof keyboard |
| Coupled status display | When the tested piece is well coupled with the probe, the icon in the upper left corner shows |
| Optional Accessories | High temperature probe (below 550 degrees), cast iron probe, small diameter probe, printer and communication printing connection, microcomputer communication software |
Packing list
host x1, probe x1, coupling agent x1, battery x2, instruction manual x1, warranty card x1, certificate x1, suitcase x1.
After-sales instructions
Warranty days: 365 days
