Specifications
| Measurement range | 0.7~350mm |
| Probe Frequency | 5MHz |
| Probe style | Integrated probe |
| Measurement error | ±(1%H±0.1)mm |
| Display resolution | 0.1mm |
| unit system | mm |
| Data storage method | Manually stored measurements |
| Storage Capacity | 600 Measured values |
| Speed of sound | 1000~9990m/s |
| Display | LCD screen |
| Operating language | Chinese |
| Environmental temperature | -10~60℃ |
| Working Relative Humidity | <90%RH |
| Power Supply | 1.2-1 alkaline battery or rechargeable battery |
| Host size | 122*50*24mm |
| Application | Thickness of Boiler, Pressure Vessel, Pipe, Metal Workpiece, Glass, Plastic, Organic Glass, etc |
| Coupled status display | When the tested part is well coupled with the probe |
| shutdown mode | Standby for five minutes will automatically shut down |
Packing list
host x1, probe x1, coupling agent x1, battery x2, instruction manual x1, warranty card x1, certificate x1, suitcase x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3088/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
