Specifications
| Instrument type | Bridge thermostatic Controller |
| Protection level | III/FL |
| Protection level | IP20 |
| Temperature range | RT+10~150℃ |
| Temperature Fluctuation | 0.1±K |
| Temperature Display mode | LED |
| Temperature Control mode | Intelligent PID control |
| Temperature sensor | Pt100 |
| Temperature sensor | optional |
| Heating power | 3000W |
| Pump type | Pressure/suction pump |
| Pump adjustability | without |
| Maximum pump pressure | 0.2bar |
| Maximum suction of pump | 0.1bar |
| Flow rate of pump | 12L/min |
| Pump connection interface | M16x1 |
| Minimum bath depth required | 150mm |
| Dimensions | (345~885)*200*336mm |
| Temperature Resolution | 0.1℃ |
| Light alarm | Yes. |
| audible alarm | Yes. |
| Temperature overrun alarm | Yes. |
| The temperature is not enough alarm | Yes. |
| secondary protection | Yes. |
| Low level protection | Yes. |
| Temperature range | 0~260℃ |
| Calibrating options | Yes. |
| Allow continuous operation | 100% |
| Environmental temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
| RS232 interface | optional |
| USB port | optional |
| Weight | 10kg |
| Power supply Voltage | 200~230VAC/50Hz |
| Input Power | 3100W |
| Instrument noise | ≤45db |
| Technical parameter standard | DIN 12876 |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/30895/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
