Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | F0.5：0~0.5mm；F1.2：0~1.25mm；F3：0~3mm；F5：0~5mm；F9：0~9mm；N1.2：0~1.25mm |
| margin of error | ±3% |
| Resolution | 0.1μm|1μm|0.01mm |
| Minimum measurement surface | F0.5：6mm；F1.2：9mm；F3：12mm；F5：20mm；F9：20mm；N1.2：9mm |
| probe | Integrated probe |
| Power Supply | 2 * AA battery |
| Standards | GB/T 4956-1985、GB/T 4957-1985、JB/T 8393-1996、JJG 889-95、JJG 818-93 |
| system language | Chinese, English |
| Display screen | 2.4 inch TFT high definition color screen, 320 * 240 pixels, large digital display |
| Machine Weight | 220G (including battery) |
| Machine size | 150*68*33mm |
| statistical function | Lite mode, Monitoring mode, Statistics mode, MIN Minimum capture |
| Data storage | 10,000 Measured values |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3102/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
