Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 10~9000μm |
| margin of error | ±3% |
| Resolution | 1μm |
| Minimum measurement surface | Φ7mm |
| Minimum radius of curvature | Convex 1.5mm; Concave 6mm |
| thinnest substrate | 0.5mm |
| statistical function | MAX Maximum, MIN Minimum, Average |
| icon function | none |
| Power Supply | 2 * 1.5V battery |
| Calibrated Certificate | none |
| system language | Chinese |
| Display screen | 4-Digit LCD digital display |
| supporting software | none |
| Machine Weight | 160G (including battery) |
| Machine size | 51*126*27mm |
| Data storage | 600 Measured values |
| power consumption | Maximum power consumption 100mw |
| Operating temperature | 0~40℃ |
| Voltage prompt | Upper right corner display icon |
| Relative Humidity | ≤90%RH |
Packing list
host x1, probe x1, standard sample x1, manual x1, warranty card x1, certificate x1, No. 7 battery x1, suitcase x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3109/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
