Specifications
| Effective test area | 10±0.05cm² |
| Measuring range | ≤ 15s, 15-300s, ≥ 300s three-speed conversion |
| Accuracy | 0.1s |
| resolution | 0.1s |
| Measuring range | 0~9999s |
| test pressure | 100 ± 1KPa |
| display | 3.2In LCD display, real-time display of test data |
| Vacuum range | I: 50.66kPa ~ 29.33kPa; <--sep--0/>: 50.66kPa ~ 48kPa; <--sep--0/>: 50.66kPa ~ 48kPa |
| System Volume | Large vacuum Volume (380 ± 1) ml; small vacuum Volume (38 ± 1) ml |
| display | 3.2In LCD display, real-time display of test data |
| printout | Comes with silent thermal printing |
| Operating Environment | Temperature (20 ± 10 ℃), humidity < 85% |
| Dimensions | 300*375*400mm |
| Weight | About 30kg |
Packing list
Host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31316/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
