Specifications
| Drop height | 300~1500mm |
| test load | 0-80Kg |
| Baseplate Film thickness | 10mm (solid iron plate) |
| Maximum specimen size | 1000*800*1000mm |
| Baseplate size | 1700*1200mm |
| Drop height error | ±10mm |
| Dimensions | ≈1700*1200*2315mm |
| Net Weight | About 300kg |
| Test method | Face, corner, edge |
| Operation mode | electric |
| Drop height error | 1% |
| Impact panel parallelism error | ≤1° |
| Drop plane error | <1° |
| Power | 380V |
| power | 1.85KWA |
| Baseplate size | 180*180mm |
Packing list
Host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31329/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
