Specifications
| Needle combustion device | Stainless steel, inner hole φ 0.5 +/- 0.1mm, outer diameter ≤ φ 0.9mm, length ≥ 35mm |
| Combustion angle | Vertical (when adjusting and measuring flame height) or tilted 45 ° (when testing) |
| Combustion gas | 95% butane or propane gas |
| Ignition paving layer | White pine board (thickness 10mm), the surface is covered with a layer of 12~ 30g/m2 standard silk paper, 200mm +/- 5mm away from the flame application |
| Glowing wire temperature | RT+~1000℃ |
| Flame temperature requirements | From 100 +/- 2 ℃ to 700 ℃ +/- 3 ℃, it should be completed within 23.5 +/- 1.0s |
| flame height | 12Mm +/- 1mm, height measurement device |
| Flame time | 0s~ 999.9s adjustable, generally set to 30s |
| Test space | ≥ 0.5m3, black background, (can be customized according to customer requirements 0.75 m3 cubic or 1 m3) |
| Thermocouple | K type insulated armored galvanic couple (φ 0.5mm) |
| Test time procedure | Automatic control, independent ventilation system |
| Test Power Supply | 220V/AC，50Hz |
Packing list
host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
