Specifications
| test space | 0.5M3, D x W x H 60x95x90cm |
| Dimensions | W x D x H 113x57x120cm |
| Glowing wire | 4.0mm diameter ring made of nickel/chromium wire |
| thermocouple | 0.5mm armored filament thermocouple, capable of high temperature of 1050 ℃ |
| Heating current | When the temperature is 960 ℃, the current is between 120 and 150A |
| Force applied to the test | 0.8~ 1.2N, and limit the pressing depth to at least 7mm |
| Timer | Ignition duration (Ti) and flame extinguishment time (Te) can be recorded |
| Glowing wire temperature | 500~1000 ℃, digital display adjustable |
| temperature tolerance error | ± 10 ℃ (500~750 ℃), ± 15 ℃ (750~1000 ℃), the temperature is ± 0.5 grade |
Packing list
Host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31345/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
