Specifications
| Test station | Six (working simultaneously) |
| test angle | 0- ± 180 ° (scale dial plus needle indication, manually adjustable) |
| Odd folding angle display and adjustment | Pointer indicator scale dial, manual adjustment of eccentric shaft |
| Test speed | 5-60 times/min (knob speed regulation, LCD display) |
| Total Counter of blue and white times | 0-999999 times (can be preset, and the number of times reached will automatically stop) |
| Bending conduction Counter | 0-999999 times (the conduction is automatically counted separately, one group is disconnected, and the counting is automatically stopped) |
| Hook Weight | Six each for 50/100/200/300/500g |
| Hand tip test fixture | Six sets of non-slip, not easy to damage the sample special fixture |
| Test fixing rod | Can be adjusted up and down, fixed at the lower end of the product, the test is more in line with the standard |
| Machine size | 120Lx600Wx800H（mm） |
| Machine Weight | 100kg |
| Power | AC220V, 50HZ |
Packing list
Host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
