Specifications
| Test station | 4 (working at the same time) |
| Load Weight | Four each of 50, 100, 200, 300, and 500g (optional) |
| Number of trials Counter | 0~99999999 times (can be preset, LCD display) |
| Test conduction count | 0~999999 times (four-station conduction automatic counting, disconnection automatic stop counting) |
| Test speed | 5~ 60 times/min (knob adjustable, LCD display) |
| test stroke | 0~60mm (manually adjustable) |
| Conventional clamping range of test fixtures | 60 × 70mm (manually adjustable) |
| Adjustable range of test rod fixing device | 0~180mm |
| Dimensions | 500×400×550mm |
| Machine Weight | 25kg |
| Power | AC220V、50HZ |
Packing list
Host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
