Specifications
| Measure maximum load | 50Kg, 20Kg, 5Kg |
| Minimum analysis capability | 0.01Kg or 1g |
| Maximum measurement height | 150mm |
| Minimum fine-tuning distance | 0.01m |
| Measuring speed range | 0-100mm/min |
| X-axis movement range | 0-75mm |
| Y-axis movement range | 0-75mm |
| Transmission mechanism | ball screw |
| Drive motor | Panasonic servo motor |
| Appearance size | 360x260x940mm |
| Weight | 67Kg |
| Power | 220V/50Hz |
Packing list
Host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31382/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
