Specifications
| Capacity selection | 1T (Miscellaneous force value optional) |
| Force measurement Accuracy | ±0.5 % |
| Force resolution | 1/300000 |
| Effective force range | 1~100%FS |
| Deformation indication Accuracy | ±0.5% |
| Test speed range | 1~ 500mm/min (can be set arbitrarily) |
| Test maximum stroke | Effective 500mm |
| Effective test space | Left and right 380mm, front and rear < unk > |
| Force unit | g、kg、N、LB、KN |
| Downtime mode | Upper and lower limit safety settings, emergency stop button, program power and elongation settings |
| How to get points | Manual point taking and preset point taking (20 points) during the test can be used for tensile and pressure holding tests |
| Machine size | 850×510×1400mm(W×D×H) |
| Machine Weight | About 120kg |
Packing list
Tension machine X1, operation software X1, computer X1, strong pliers drawing fixture X1, manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31389/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
