Specifications
| Force range | 1~50KN (5000kg) |
| Plate size | 1500*1500mm |
| Dimensions | 1500*2100*2100mm |
| Force Resolution | 1N |
| Error of indication | ±1% |
| Indication of variability | ≤1% |
| Zero Return Error | ±0.1%FS |
| deformation error | ±1mm |
| Stacking test Preset load Relative fluctuation | ±2% |
| Pressurization speed | 1~300mm/min |
| Pressurization speed relative error | ± 2% (within 1~ 300mm) |
| return speed | 1~300mm/min |
| Pressurization speed | 10mm/min (adjustable) |
| Stacking test pressurization speed | 2mm/min (adjustable) |
| Upper and lower platen flatness | ±0.25mm |
| Plate parallelism | ≤1.5mm |
| Working Travel | 1500mm |
| test space | 1500*1500*1500mm |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31415/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
