Specifications
| Flow Rate | Class I ultrapure water ≥ 2L/min |
| Ultrapurification Unit Capacity | 480L/day |
| Produced water quality | tertiary water |
| Ultrapure water quality | Class I ultrapure water |
| Inlet source | tap water |
| Operating Environment | Temperature 5-40 ℃, avoid direct sunlight |
| Power | 220V/50HZ, Power: 150W |
| Interface | Optional RS232 interface |
| Inlet source | TDS: < 200ppm; pH: 6.5-8; Free Chlorine: < 1ppm; Pressure MIN Minimum: 0.2MPa; Pressure MAX Maximum: 0.5MPa; Temperature: 5-35 ℃ |
| Pure Flow Rate index | Conductivity: < 10μs/cm@25 ℃, meeting the Chinese laboratory water standard GB/T6682-2008 three-level water standard |
| Ultrapure Flow Rate index | Electrical resistivity: 18.25MΩ .cm@25 ℃; particles (> 0.2μm): < 1/ml; microorganisms < 1/ml; TOC < 10ppb |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31422/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
