Specifications
| Test direction | Vertical + horizontal + front and rear (automatic switching, can run vibration directions of different frequencies at the same time) |
| Maximum test Weight | 0-60kg |
| Test platform size | 1000*1000mm |
| Control method | PLC touch screen type (Linear dispersion diagram is directly displayed on the screen, and data can be directly stored with USB interface) |
| Frequency adjustment range | 1-600HZ |
| precision | Frequency can be displayed to 0.1HZ, precision 0.1HZ |
| amplitude | 0~5mm (random type) |
| Vibration waveform | sine wave |
| Maximum acceleration | 10G |
| function | Sweep frequency, fixed frequency, programmable, time control |
| Frequency doubling function (0.01Hz) | 8 segments are multiplied ① low to high frequency ② high to low frequency ③ low to high and then to low frequency/recyclable |
| Logarithmic function (0.01Hz) | ① down to the upper frequency ② up to the lower frequency ③ down to the upper frequency and then to the lower frequency --3 modes logarithmic/recyclable |
| Power | AC220V 50HZ |
Packing list
Host X1, power cord X1, manual X1, warranty card X1, certificate X1, fixed tie X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31460/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
